Draw Over Other Apps Permission in Android

Draw Over Other Apps Permission in Android

In this post, we will learn how to request runtime permission of Draw over Other Apps.

By turning on this permission, we will show our app icon or perform any task from our app to overlay on other apps.

The best Example for this is, Facebook chat Heads, for showing facebook chat heads from messenger, we have to give permission of draw over other apps.

Preview:

Draw Over Other Apps Runtime Permission Android

Runtime Permission request is used from Android Marshmallow(6.0), before Android M this permission given by default.

To request other permissions, you can see this post, but for Draw over other apps permission, we will change our request criteria to get this permission.

So, Let's Start,

Write permission in AndroidManifest.xml

 <uses-permission android:name="android.permission.SYSTEM_ALERT_WINDOW" />

After that, we will create a button in our XML file to check permission and also we created a TextView to set the text of permission granted or not.

XML activity

 <?xml version="1.0" encoding="utf-8"?>
 <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
   xmlns:app="http://schemas.android.com/apk/res-auto"
   xmlns:tools="http://schemas.android.com/tools"
   android:layout_width="match_parent"
   android:layout_height="match_parent"
   android:orientation="vertical"
   tools:context=".NextActivity">
   <TextView
     android:layout_width="wrap_content"
     android:layout_height="wrap_content"
     android:id="@+id/textview_next"
     android:text="Permission"
     android:textSize="16dp"
     android:padding="20dp">
   </TextView>
   <Button
     android:layout_width="wrap_content"
     android:layout_height="wrap_content"
     android:id="@+id/checkbutton"
     android:text="Check Pemission"
     app:layout_constraintTop_toBottomOf="@id/textview_next">
   </Button>
 </LinearLayout>

After that, in our java file we will request our permission and also we check if our app runs on greater than Android M devices or not.

Java Activity

 package studio.harpreet.sampleproject;
 import android.content.Intent;
 import android.content.SharedPreferences;
 import androidx.appcompat.app.AppCompatActivity;
 import android.net.Uri;
 import android.os.Build;
 import android.os.Bundle;
 import android.provider.Settings;
 import android.view.View;
 import android.widget.Button;
 import android.widget.TextView;
 import android.widget.Toast;
 public class NextActivity extends AppCompatActivity {
   TextView tv;
   Button btn;
   @Override
   protected void onCreate(Bundle savedInstanceState) {
     super.onCreate(savedInstanceState);
     setContentView(R.layout.activity_next);
     tv = findViewById(R.id.textview_next);
     btn = findViewById(R.id.checkbutton);
     btn.setOnClickListener(new View.OnClickListener() {
       @Override
       public void onClick(View view) {
         if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.M) {
           if(Settings.canDrawOverlays(NextActivity.this))
           {
             tv.setText("Permission Granted");
           }
           else
           {
             Intent intent = new Intent(Settings.ACTION_MANAGE_OVERLAY_PERMISSION, Uri.parse("package:"+getPackageName()));
             Toast.makeText(NextActivity.this, "Please Give Permission to Draw over other apps", Toast.LENGTH_SHORT).show();
             startActivity(intent);
           }
         }
       }
     });
   }
 }

Where your app used to draw overlays, check if permission requested or not to avoid Exceptions.
