How to create an Admob Banner ad in Android App | Place Admob Banner Ads

If you are an Android Developer and want to earn money from your android app. Then you have to place Ads in your Android App.

There is some type of ads you can place in your Android App.

• Banner Ads (Small Mini ads)
• Interstitial Ads (Full-Screen Ads)
• Rewarded Ads ( Video Ads)

Today, In this post we learn how to create a Banner ad in your Android App.

To place a Banner Ad, we have to create a new Admob Account and add your app there and then create a new Banner Ad there and create Ad unit Id. seen in the pictures below.

Your Application Name

Type of Ad

Banner Ad set-up

Then, in Android Studio, first, we have to add new google ads dependency in our app-level Gradle file.

app-level Gradle file

 implementation 'com.google.android.gms:play-services-ads:18.3.0'

Then, we create a banner ad layout in our XML file.

MainActivity.xml

 <?xml version="1.0" encoding="utf-8"?>
 <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
   xmlns:app="http://schemas.android.com/apk/res-auto"
   xmlns:tools="http://schemas.android.com/tools"
   android:layout_width="match_parent"
   android:layout_height="match_parent"
   tools:context=".MainActivity">
   <TextView
     android:layout_width="wrap_content"
     android:layout_height="wrap_content"
     android:text="Hello World!"
     app:layout_constraintBottom_toBottomOf="parent"
     app:layout_constraintLeft_toLeftOf="parent"
     app:layout_constraintRight_toRightOf="parent"
     app:layout_constraintTop_toTopOf="parent" />
   <com.google.android.gms.ads.AdView
     android:id="@+id/adView"
     android:layout_width="wrap_content"
     android:layout_height="wrap_content"
     android:layout_alignParentBottom="true"
     android:layout_centerHorizontal="true"
     android:layout_gravity="bottom|center"
     app:adSize="BANNER"
     app:adUnitId="@string/bannerAdMobId">
     </com.google.android.gms.ads.AdView>
 </LinearLayout>

Then place your application id in your manifest.xml under meta-data tag

For Application Id open your Admob Account and open your Ad unit then click on implementation instructions, Upper one which contains tilde (~) sign is your Application id and another one is your Ad unit Id.

Application Id and Ad Unit Id

AndroidManifest.xml

 <meta-data
       android:name="com.google.android.gms.ads.APPLICATION_ID"
       android:value="@string/bannerAdAppId" />

Then create an instance and find the id in MainActivity.java and Load your Banner Ad

MainActivity.java

 public class MainActivity extends AppCompatActivity {
   AdView madview;
   @Override
   protected void onCreate(Bundle savedInstanceState) {
     super.onCreate(savedInstanceState);
     setContentView(R.layout.activity_main);
     madview = findViewById(R.id.adView);
     AdRequest adRequest = new AdRequest.Builder().addTestDevice("XXXXXXXXXXXXXXXXXXXXXX").build();
     madview.loadAd(adRequest);
   }
 }

 Here, we load our ad and also add a test device because we run this ad through debugging. For test device id you can see logs of Ad-request inside run tab in Android Studio.

Find Test Device Id to run Banner Ad
